VCC2X105-12IO7
RoHS
RoHS compliant
RoHS compliantPackage ECO-PAC2
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Thyristor SCR Module 1.2KV 2.4KA 18-Pin ECO-PAC 2
PDF
/
Inventory: 1000
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case ECO-PAC2
Number of Pins 18
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2002
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
HTS Code 8541.30.00.80
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number VCC2X
Pin Count 14
JESD-30 Code R-XUFM-X14
Qualification Status Not Qualified
Number of Elements 2
Configuration SEPARATE, 2 ELEMENTS
Case Connection ISOLATED
RMS Current (Irms) 180A
Hold Current 200mA
Trigger Device Type SCR
Voltage - Off State 1.2kV
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 2250A 2400A
Current - Gate Trigger (Igt) (Max) 150mA
Current - On State (It (RMS)) (Max) 180A
Structure Independent - All SCRs
Repetitive Peak Off-state Voltage 1200V
Current - On State (It (AV)) (Max) 105A
Repetitive Peak Reverse Voltage 1200V
Number of SCRs, Diodes 2 SCRs
Compliance
RoHS Status ROHS3 Compliant
