VCA105-12IO7
RoHS
/
Package ECO-PAC2
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Bulk Common Anode - All SCRs Chassis Mount SCR SCR Module 2250A 2400A 150mA 1200V -40C~125C TJ
PDF
/
Inventory: 3554
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case ECO-PAC2
Number of Pins 11
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2002
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 11
HTS Code 8541.30.00.80
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number VC*105
Pin Count 11
Qualification Status Not Qualified
Number of Elements 2
Configuration COMMON ANODE, 2 ELEMENTS
Case Connection ISOLATED
RMS Current (Irms) 180A
Hold Current 200mA
Trigger Device Type SCR
Voltage - Off State 1.2kV
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 2250A 2400A
Current - Gate Trigger (Igt) (Max) 150mA
Current - On State (It (RMS)) (Max) 180A
Structure Common Anode - All SCRs
Repetitive Peak Off-state Voltage 1200V
Current - On State (It (AV)) (Max) 105A
Repetitive Peak Reverse Voltage 1200V
Number of SCRs, Diodes 2 SCRs
Compliance
RoHS Status RoHS Compliant
