MCMA35P1600TA
RoHS
RoHS compliant
RoHS compliantPackage TO-240AA
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR Modules Thyristor Module Phase Leg
PDF
/
Inventory: 3043
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Desc. of Quick-Connects 2G-2GR
Desc. of Screw Terminals A-K-AK
Number of SCRs, Diodes 2 SCRs
Repetitive Peak Reverse Voltage 1600V
Non-Repetitive Pk On-state Cur 560 A
Current - On State (It (AV)) (Max) 35A
Leakage Current (Max) 6mA
Structure Series Connection - All SCRs
Current - On State (It (RMS)) (Max) 55A
On-State Current-Max 35000A
Current - Gate Trigger (Igt) (Max) 78mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 520A 560A
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Voltage - Off State 1.6kV
Trigger Device Type SCR
Hold Current 200mA
RMS Current (Irms) 55A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Subcategory Silicon Controlled Rectifiers
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2014
Packaging Bulk
Operating Temperature -40°C~140°C TJ
Physical
Package / Case TO-240AA
Mounting Type Chassis Mount
Mount Chassis Mount
