MCMA265PD1600KB
RoHS
RoHS compliant
RoHS compliantPackage Y1-CU
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Bridge Rectifiers Thyristor/Diode Module
PDF
/
Buying Options
Total Price: USD $360.49
Unit Price: USD $360.494769
≥1 USD $360.494769
≥201 USD $143.840011
≥501 USD $139.033484
≥999 USD $136.658448
Inventory: 7880
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Desc. of Quick-Connects G-GR
Desc. of Screw Terminals A-K-AK
Number of SCRs, Diodes 1 SCR, 1 Diode
Repetitive Peak Reverse Voltage 1600V
Current - On State (It (AV)) (Max) 268A
Leakage Current (Max) 30mA
Repetitive Peak Off-state Voltage 1600V
Structure Series Connection - SCR/Diode
Current - On State (It (RMS)) (Max) 421A
Current - Non Rep. Surge 50, 60Hz (Itsm) 8500A 9180A
Voltage - Gate Trigger (Vgt) (Max) 2V
Voltage - Off State 1.6kV
Trigger Device Type SCR
Hold Current 150mA
RMS Current (Irms) 421A
Case Connection ISOLATED
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-CUFM-X5
Pin Count 5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2016
Packaging Bulk
Operating Temperature -40°C~140°C TJ
Physical
Package / Case Y1-CU
Mounting Type Chassis Mount
Mount Chassis Mount
