MCD500-16IO1
RoHS
/
Package WC-500
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
MOD THYRISTOR DUAL 1200V WC-500
PDF
/
Inventory: 2686
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case WC-500
Number of Pins 500
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2005
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Base Part Number MC*500
RMS Current (Irms) 1.294kA
Hold Current 1A
Voltage - Off State 1.6kV
Voltage - Gate Trigger (Vgt) (Max) 3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 16500A @ 50Hz
Current - Gate Trigger (Igt) (Max) 300mA
Current - Hold (Ih) (Max) 1A
Current - On State (It (RMS)) (Max) 1294A
Structure Series Connection - SCR/Diode
Current - On State (It (AV)) (Max) 545A
Number of SCRs, Diodes 1 SCR, 1 Diode
Compliance
RoHS Status RoHS Compliant
