MCD26-16IO1B
RoHS
RoHS compliant
RoHS compliantPackage TO-240AA
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
MOD THYRISTOR/DIO 1600V TO-240AA
PDF
/
Buying Options
Total Price: USD $25.47
Unit Price: USD $25.4672
≥1 USD $25.4672
≥10 USD $22.6336
≥100 USD $19.796128
≥500 USD $16.892726
Inventory: 37
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case TO-240AA
Number of Pins 5
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2004
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Additional Feature UL RECOGNIZED
Subcategory Silicon Controlled Rectifiers
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MC*26
Pin Count 5
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE WITH BUILT-IN DIODE
Case Connection ISOLATED
Max Repetitive Reverse Voltage (Vrrm) 1.6kV
RMS Current (Irms) 50A
Reverse Voltage 1.6kV
Hold Current 200mA
Trigger Device Type SCR
Voltage - Off State 1.6kV
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 520A 560A
Current - Gate Trigger (Igt) (Max) 100mA
On-State Current-Max 27000A
Structure Series Connection - SCR/Diode
Repetitive Peak Off-state Voltage 1600V
Leakage Current (Max) 3mA
Current - On State (It (AV)) (Max) 32A
Number of SCRs, Diodes 1 SCR, 1 Diode
Desc. of Screw Terminals A-K-AK
Desc. of Quick-Connects G-GR
Dimensions
Height 30mm
Length 92mm
Width 20.8mm
Compliance
RoHS Status ROHS3 Compliant
