MCD255-18IO1
RoHS
RoHS compliant
RoHS compliantPackage Y1-CU
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Thyristor SCR Module 1.8KV 9.6KA 5-Pin Y1-CU
PDF
/
Buying Options
Total Price: USD $350.51
Unit Price: USD $350.510165
≥1 USD $350.510165
≥201 USD $139.856673
≥501 USD $135.182749
≥999 USD $132.873357
Inventory: 1566
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case Y1-CU
Number of Pins 5
Technical
Operating Temperature -40°C~140°C TJ
Packaging Bulk
Published 2000
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Additional Feature UL RECOGNIZED
Subcategory Silicon Controlled Rectifiers
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MC*255
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE WITH BUILT-IN SERIES DIODE
Case Connection ISOLATED
RMS Current (Irms) 450A
Hold Current 150mA
Trigger Device Type SCR
Voltage - Off State 1.8kV
Voltage - Gate Trigger (Vgt) (Max) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 9000A 9600A
Current - On State (It (RMS)) (Max) 450A
Structure Series Connection - SCR/Diode
Repetitive Peak Off-state Voltage 1800V
Leakage Current (Max) 40mA
Current - On State (It (AV)) (Max) 250A
Non-Repetitive Pk On-state Cur 9600 A
Repetitive Peak Reverse Voltage 1800V
Number of SCRs, Diodes 1 SCR, 1 Diode
Desc. of Screw Terminals A-K-AK
Desc. of Quick-Connects G-GR
