MCC310-08IO1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Thyristor SCR Module 800V 9.8KA 7-Pin Y2-DCB
PDF
/
Buying Options
Total Price: USD $278.92
Unit Price: USD $278.921666
≥1 USD $278.921666
≥200 USD $111.291907
≥500 USD $107.573774
≥1000 USD $105.735714
Inventory: 8685
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case Module
Number of Pins 7
Technical
Operating Temperature -40°C~140°C TJ
Packaging Bulk
Published 2000
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
Additional Feature UL RECOGNIZED
HTS Code 8541.30.00.80
Subcategory Silicon Controlled Rectifiers
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MC*310
Pin Count 7
Qualification Status Not Qualified
Number of Elements 2
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Case Connection ISOLATED
RMS Current (Irms) 500A
Hold Current 150mA
Trigger Device Type SCR
Voltage - Off State 800V
Voltage - Gate Trigger (Vgt) (Max) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 9200A 9800A
On-State Current-Max 520000A
Current - On State (It (RMS)) (Max) 500A
Structure Series Connection - All SCRs
Repetitive Peak Off-state Voltage 800V
Leakage Current (Max) 40mA
Current - On State (It (AV)) (Max) 320A
Non-Repetitive Pk On-state Cur 9800 A
Repetitive Peak Reverse Voltage 800V
Number of SCRs, Diodes 2 SCRs
Desc. of Screw Terminals A-K-AK
Desc. of Quick-Connects 2G-2GR
Compliance
RoHS Status ROHS3 Compliant
