MCC225-12IO1
RoHS
RoHS compliant
RoHS compliantPackage Y1-CU
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Thyristor SCR Module 1.2KV 8.5KA 7-Pin Y1-CU
PDF
/
Buying Options
Total Price: USD $328.74
Unit Price: USD $328.735718
≥1 USD $328.735718
≥201 USD $131.1679
≥501 USD $126.784127
≥999 USD $124.619155
Inventory: 3700
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case Y1-CU
Number of Pins 7
Technical
Operating Temperature -40°C~140°C TJ
Packaging Bulk
Published 2009
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
Additional Feature UL RECOGNIZED
HTS Code 8541.30.00.80
Subcategory Silicon Controlled Rectifiers
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MC*225
Qualification Status Not Qualified
Number of Elements 2
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Case Connection ISOLATED
RMS Current (Irms) 400A
Reverse Voltage 1.2kV
Hold Current 150mA
Trigger Device Type SCR
Voltage - Gate Trigger (Vgt) (Max) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 8000A 8500A
On-State Current-Max 221000A
Current - On State (It (RMS)) (Max) 400A
Structure Series Connection - All SCRs
Repetitive Peak Off-state Voltage 1200V
Leakage Current (Max) 40mA
Current - On State (It (AV)) (Max) 221A
Non-Repetitive Pk On-state Cur 8500 A
Number of SCRs, Diodes 2 SCRs
Desc. of Screw Terminals A-K-AK
Desc. of Quick-Connects 2G-2GR
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
