MCC21-12IO8B
RoHS
RoHS compliant
RoHS compliantPackage TO-240AA
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Bulk Series Connection - All SCRs Chassis Mount SCR SCR Module 320A 350A 65mA 1200V -40C~125C TJ
PDF
/
Inventory: 2423
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Voltage - Off State 1.2kV
Trigger Device Type SCR
Hold Current 100mA
RMS Current (Irms) 33A
Case Connection ISOLATED
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Number of Elements 2
Qualification Status Not Qualified
Base Part Number MC*21
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Silicon Controlled Rectifiers
Additional Feature UL RECOGNIZED
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2000
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Desc. of Quick-Connects 2G
Desc. of Screw Terminals A-K-AK
Number of SCRs, Diodes 2 SCRs
Repetitive Peak Reverse Voltage 1200V
Current - On State (It (AV)) (Max) 21A
Repetitive Peak Off-state Voltage 1200V
Structure Series Connection - All SCRs
Current - On State (It (RMS)) (Max) 33A
On-State Current-Max 21000A
Current - Gate Trigger (Igt) (Max) 65mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 320A 350A
Voltage - Gate Trigger (Vgt) (Max) 1V
Physical
Number of Pins 5
Package / Case TO-240AA
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Compliance
RoHS Status ROHS3 Compliant
