MCC19-16IO8B
RoHS
RoHS compliant
RoHS compliantPackage TO-240AA
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Bulk Series Connection - All SCRs Chassis Mount SCR SCR Module 400A 420A 100mA 1600V -40C~125C TJ
PDF
/
Inventory: 5091
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case TO-240AA
Number of Pins 5
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2009
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Additional Feature UL RECOGNIZED
Subcategory Silicon Controlled Rectifiers
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MC*19
Pin Count 5
Qualification Status Not Qualified
Number of Elements 2
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Case Connection ISOLATED
RMS Current (Irms) 40A
Reverse Voltage 1.6kV
Hold Current 200mA
Trigger Device Type SCR
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 400A 420A
Current - Gate Trigger (Igt) (Max) 100mA
On-State Current-Max 18000A
Current - On State (It (RMS)) (Max) 40A
Structure Series Connection - All SCRs
Repetitive Peak Off-state Voltage 1600V
Leakage Current (Max) 10mA
Current - On State (It (AV)) (Max) 25A
Non-Repetitive Pk On-state Cur 400 A
Number of SCRs, Diodes 2 SCRs
Desc. of Screw Terminals A-K-AK
Desc. of Quick-Connects 2G
Compliance
RoHS Status ROHS3 Compliant
