TD425N18KOFHPSA2
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR MODULE 1800V 800A MODULE
PDF
/
Buying Options
Total Price: USD $594.74
Unit Price: USD $594.738448
≥1 USD $594.738448
≥200 USD $237.305362
≥500 USD $229.375446
≥1000 USD $225.45644
Inventory: 2686
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Number of SCRs, Diodes 1 SCR, 1 Diode
Current - On State (It (AV)) (Max) 471A
Repetitive Peak Off-state Voltage 1800V
Structure Series Connection - SCR/Diode
Current - On State (It (RMS)) (Max) 800A
Max Forward Surge Current (Ifsm) 12.5kA
Current - Gate Trigger (Igt) (Max) 250mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 14500A @ 50Hz
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Trigger Device Type SCR
Hold Current 300mA
Reverse Voltage 1.8kV
Max Repetitive Reverse Voltage (Vrrm) 1.8kV
Halogen Free Not Halogen Free
Case Connection ISOLATED
Output Current 800A
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
JESD-30 Code R-XXFM-X5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Tray
Operating Temperature 125°C TJ
Physical
Number of Pins 425
Package / Case Module
Mounting Type Chassis Mount
Mount Screw
Supply Chain
Factory Lead Time 8 Weeks
