TD280N18SOFHPSA1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR MODULE 1800V 520A MODULE
PDF
/
Buying Options
Total Price: USD $84.3
Unit Price: USD $84.2952
≥1 USD $84.2952
≥10 USD $76.956
≥100 USD $73.420679
≥500 USD $69.61365
Inventory: 55
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of SCRs, Diodes 1 SCR, 1 Diode
Repetitive Peak Reverse Voltage 1800V
Current - On State (It (AV)) (Max) 280A
Repetitive Peak Off-state Voltage 1800V
Structure Series Connection - SCR/Diode
Current - On State (It (RMS)) (Max) 520A
Current - Gate Trigger (Igt) (Max) 150mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 9000A @ 50Hz
Voltage - Gate Trigger (Vgt) (Max) 2V
Voltage - Off State 1.8kV
Trigger Device Type SCR
Case Connection ISOLATED
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
JESD-30 Code R-XUFM-X5
Reference Standard IEC-747-6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
HTS Code 8541.30.00.80
Additional Feature UL RECOGNIZED
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Tray
Operating Temperature -40°C~130°C
Physical
Surface Mount NO
Package / Case Module
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 16 Weeks
