S8010VTP
RoHS
RoHS compliant
RoHS compliantPackage TO-251-3 Short Leads, IPak, TO-251AA
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR NON-SENS 800V 10A TO-251
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.559373
≥1 USD $1.559373
≥10 USD $1.471108
≥100 USD $1.387844
≥500 USD $1.309286
≥1000 USD $1.235179
Inventory: 1398
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Current - Off State (Max) 10μA
Critical Rate of Rise of Off-State Voltage-Min 200V/us
Voltage - On State (Vtm) (Max) 1.6V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 100 A
Leakage Current (Max) 0.5mA
Current - Hold (Ih) (Max) 30mA
Current - Gate Trigger (Igt) (Max) 15mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 83A 100A
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Voltage - Off State 800V
Trigger Device Type SCR
Hold Current 30mA
RMS Current (Irms) 10A
Case Connection ANODE
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 40
Current Rating 6.4A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Voltage - Rated DC 800V
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2004
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Package / Case TO-251-3 Short Leads, IPak, TO-251AA
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
