S6055WTP
RoHS
RoHS compliant
RoHS compliantPackage TO-218X-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
NON-SENSITIVE GATE 55.0A 600V
PDF
/
Buying Options
Total Price: USD $5.75
Unit Price: USD $5.749708
≥1 USD $5.749708
≥10 USD $5.424261
≥100 USD $5.117218
≥500 USD $4.82757
≥1000 USD $4.554309
Inventory: 6151
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Repetitive Peak Reverse Voltage 600V
Current - Off State (Max) 10μA
Critical Rate of Rise of Off-State Voltage-Min 500V/us
Voltage - On State (Vtm) (Max) 1.8V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 650 A
Current - On State (It (AV)) (Max) 35A
Leakage Current (Max) 2mA
Repetitive Peak Off-state Voltage 600V
Current - On State (It (RMS)) (Max) 55A
Current - Gate Trigger (Igt) (Max) 40mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 550A 650A
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Voltage - Off State 600V
Trigger Device Type SCR
Hold Current 60mA
RMS Current (Irms) 55A
Case Connection ANODE
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-D3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Form SOLDER LUG
Terminal Position SINGLE
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2004
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Package / Case TO-218X-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 19 Weeks
