S6025NTP
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR NON-SENS 600V 25A TO-263
PDF
/
Inventory: 9923
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Current - Off State (Max) 10μA
Critical Rate of Rise of Off-State Voltage-Min 325V/us
Voltage - On State (Vtm) (Max) 1.6V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 350 A
Leakage Current (Max) 1mA
Current - Hold (Ih) (Max) 50mA
Current - Gate Trigger (Igt) (Max) 35mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 300A 350A
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Voltage - Off State 600V
Trigger Device Type SCR
Hold Current 50mA
RMS Current (Irms) 25A
JEDEC-95 Code TO-263AA
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 40
Current Rating 16A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Voltage - Rated DC 600V
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Terminal Finish Matte Tin (Sn)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2004
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
