S4055R
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
Thyristor SCR 400V 650A 3-Pin(3+Tab) TO-220AB Non-Isolated Tube
PDF
/
Inventory: 946
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.78mm
Length 10.67mm
Height 9.4mm
Technical
Circuit Commutated Turn-off Time-Nom 35 μs
Holding Current-Max 50mA
Current - Off State (Max) 10μA
Critical Rate of Rise of Off-State Voltage-Min 425V/us
Voltage - On State (Vtm) (Max) 1.8V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 650 A
Current - On State (It (AV)) (Max) 35A
Leakage Current (Max) 1mA
Current - Gate Trigger (Igt) (Max) 40mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 550A 650A
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Trigger Device Type SCR
Hold Current 60mA
RMS Current (Irms) 55A
JEDEC-95 Code TO-220AB
Forward Voltage 1.8V
Configuration SINGLE
Number of Elements 1
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 40
Current Rating 55A
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Voltage - Rated DC 400V
Subcategory Silicon Controlled Rectifiers
Additional Feature HIGH RELIABILITY
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code no
JESD-609 Code e3
Published 2004
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Weight 2.299997g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
