S4006LS2
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Isolated Tab
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR SENS 400V 6A ISO TO-220
PDF
/
Buying Options
Total Price: USD $14.74
Unit Price: USD $14.74495
≥1 USD $14.74495
≥10 USD $12.09825
≥100 USD $11.72015
≥500 USD $11.34205
≥1000 USD $10.96395
Inventory: 1000
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 51 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Isolated Tab
Number of Pins 3
Technical
Operating Temperature -40°C~110°C
Packaging Bulk
Published 2001
JESD-609 Code e3
Pbfree Code no
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Additional Feature UL RECOGNIZED
Subcategory Silicon Controlled Rectifiers
Voltage - Rated DC 400V
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 260
Current Rating 3.8A
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 3
Number of Elements 1
Configuration SINGLE
JEDEC-95 Code TO-220AB
RMS Current (Irms) 6A
Hold Current 6mA
Trigger Device Type SCR
Voltage - Off State 400V
Voltage - Gate Trigger (Vgt) (Max) 800mV
Current - Non Rep. Surge 50, 60Hz (Itsm) 83A 100A
Current - Gate Trigger (Igt) (Max) 200μA
Current - Hold (Ih) (Max) 6mA
Leakage Current (Max) 0.1mA
SCR Type Sensitive Gate
Voltage - On State (Vtm) (Max) 1.6V
Critical Rate of Rise of Off-State Voltage-Min 5V/us
Current - Off State (Max) 5μA
RMS On-state Current-Max 6A
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
