EC103D1
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
LITTELFUSE EC103D1SCR THYRISTOR, 800mA, 400V, TO-92
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.171
≥1 USD $0.171
≥10 USD $0.1406
≥100 USD $0.13585
≥500 USD $0.13205
≥1000 USD $0.1273
≥1000 USD $0.114
Inventory: 188636
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Technical
Operating Temperature -40°C~110°C
Packaging Bulk
Published 2004
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Additional Feature HIGH RELIABILITY
Subcategory Silicon Controlled Rectifiers
Voltage - Rated DC 400V
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Current Rating 510mA
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Case Connection ISOLATED
RMS Current (Irms) 800mA
Hold Current 5mA
Trigger Device Type SCR
Voltage - Off State 400V
Voltage - Gate Trigger (Vgt) (Max) 800mV
Current - Non Rep. Surge 50, 60Hz (Itsm) 16A 20A
Current - Gate Trigger (Igt) (Max) 12μA
Current - Hold (Ih) (Max) 5mA
Non-Repetitive Pk On-state Cur 20 A
SCR Type Sensitive Gate
Voltage - On State (Vtm) (Max) 1.7V
Critical Rate of Rise of Off-State Voltage-Min 20V/us
Current - Off State (Max) 1μA
RMS On-state Current-Max 0.8A
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
