CLA50E1200TC
RoHS
/
Package TO-268
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
PDF
/
Inventory: 3927
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Circuit Commutated Turn-off Time-Nom 200 μs
DC Gate Trigger Voltage-Max 1.6V
DC Gate Trigger Current-Max 50mA
Holding Current-Max 100mA
RMS On-state Current-Max 79A
Repetitive Peak Reverse Voltage 1200V
Critical Rate of Rise of Off-State Voltage-Min 1000V/us
Non-Repetitive Pk On-state Cur 595 A
Leakage Current (Max) 4mA
Repetitive Peak Off-state Voltage 1200V
On-State Current-Max 50000A
Trigger Device Type SCR
Hold Current 75mA
RMS Current (Irms) 80A
Case Connection ANODE
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Additional Feature HIGH RELIABILITY
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish PURE TIN
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Physical
Weight 4.500005g
Package / Case TO-268
Mount Surface Mount
