ETZ1100N16P70HPSA1
RoHS
/
Package Module
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
THYR / DIODE MODULE DK
PDF
/
Buying Options
Total Price: USD $1028.45
Unit Price: USD $1028.449712
≥1 USD $1028.449712
≥200 USD $410.358711
≥500 USD $396.645471
≥1000 USD $389.869594
Inventory: 1164
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Chassis Mount
Package / Case Module
Technical
Operating Temperature 135°C TJ
Part Status Active
Voltage - Off State 1.6kV
Voltage - Gate Trigger (Vgt) (Max) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 33600A @ 50Hz
Current - Gate Trigger (Igt) (Max) 250mA
Current - Hold (Ih) (Max) 500mA
Current - On State (It (RMS)) (Max) 1000A
Current - On State (It (AV)) (Max) 1051A
SCR Type Standard Recovery
Voltage - On State (Vtm) (Max) 1.52V
Alternative Model
