CS218I-30PB
RoHS
/
Package TO-218-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
DIODE RECT 30A 1200V TO-218
PDF
/
Inventory: 5748
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-218-3
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8541.30.00.80
Subcategory Silicon Controlled Rectifiers
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Case Connection ISOLATED
RMS Current (Irms) 30A
Hold Current 75mA
Trigger Device Type SCR
Voltage - Off State 1.2kV
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 400A @ 100Hz
Current - Gate Trigger (Igt) (Max) 50mA
Current - On State (It (RMS)) (Max) 30A
Repetitive Peak Off-state Voltage 1200V
Non-Repetitive Pk On-state Cur 400 A
SCR Type Standard Recovery
Voltage - On State (Vtm) (Max) 2.1V
Current - Off State (Max) 20μA
Repetitive Peak Reverse Voltage 1200V
Compliance
RoHS Status Non-RoHS Compliant
