CS202-4N-2
RoHS
/
Package TO-202 Long Tab
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 2A TH TO-202
PDF
/
Inventory: 8256
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Repetitive Peak Reverse Voltage 800V
Critical Rate of Rise of Off-State Voltage-Min 10V/us
Voltage - On State (Vtm) (Max) 1.8V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 30 A
Leakage Current (Max) 0.01mA
Repetitive Peak Off-state Voltage 800V
Current - On State (It (RMS)) (Max) 4A
On-State Current-Max 4000A
Current - Gate Trigger (Igt) (Max) 200μA
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 800V
Trigger Device Type SCR
Hold Current 2mA
RMS Current (Irms) 4A
JEDEC-95 Code TO-202AB
Case Connection ANODE
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2016
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Package / Case TO-202 Long Tab
Mounting Type Through Hole
Mount Through Hole
