2N684A
RoHS
/
Package TO-208AA, TO-48-3, Stud
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR THYRISTOR TO48
PDF
/
Buying Options
Total Price: USD $5.72
Unit Price: USD $5.72
≥1 USD $5.72
Inventory: 111
Minimum: 1
-
+
Technical Details
Physical
Mount Chassis, Stud
Mounting Type Chassis, Stud Mount
Package / Case TO-208AA, TO-48-3, Stud
Technical
Operating Temperature -65°C~125°C
Packaging Bulk
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
HTS Code 8541.30.00.80
Reach Compliance Code not_compliant
Pin Count 2
RMS Current (Irms) 25A
Hold Current 50mA
Voltage - Off State 150V
Voltage - Gate Trigger (Vgt) (Max) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 200A @ 60Hz
Current - Gate Trigger (Igt) (Max) 40mA
Current - On State (It (RMS)) (Max) 25A
SCR Type Standard Recovery
Current - Off State (Max) 13mA
Compliance
RoHS Status Non-RoHS Compliant
