2N5063 PBFREE
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 0.8A 150V TO-92
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.44528
≥100 USD $0.308
≥500 USD $0.25733
≥1000 USD $0.218997
≥3000 USD $0.195043
Inventory: 3508
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Off State (Max) 1μA
Voltage - On State (Vtm) (Max) 1.7V
SCR Type Sensitive Gate
Current - On State (It (RMS)) (Max) 800mA
Current - Hold (Ih) (Max) 5mA
Current - Gate Trigger (Igt) (Max) 200μA
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 150V
Trigger Device Type SCR
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
