2N5060
RoHS
/
Package TO-92
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCRs 0.8A 30V
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 1461
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Circuit Commutated Turn-off Time-Nom 10 μs
DC Gate Trigger Voltage-Max 0.8V
DC Gate Trigger Current-Max 0.2mA
RMS On-state Current-Max 0.8A
Repetitive Peak Reverse Voltage 30V
Non-Repetitive Pk On-state Cur 10 A
Leakage Current (Max) 0.01mA
Repetitive Peak Off-state Voltage 30V
On-State Current-Max 510A
Trigger Device Type SCR
Hold Current 5mA
RMS Current (Irms) 800mA
Forward Voltage 1.7V
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PBCY-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Part Status Active
Pbfree Code no
JESD-609 Code e0
Published 2007
Packaging Bulk
Physical
Weight 453.59237mg
Package / Case TO-92
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
