TMMDB3TG
RoHS
RoHS compliant
RoHS compliantPackage DO-213AA
Category Discrete Semiconductor Products / Thyristors - DIACs, SIDACs
Description
Diacs 32 Volt Trigger
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.11115
≥1 USD $0.11115
≥10 USD $0.0912
≥100 USD $0.08835
≥500 USD $0.0855
≥1000 USD $0.08265
Inventory: 1153
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Contact Plating Tin
Mount Surface Mount
Package / Case DO-213AA
Number of Pins 2
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
HTS Code 8541.30.00.80
Subcategory Silicon Surge Protectors
Terminal Position END
Terminal Form WRAP AROUND
Peak Reflow Temperature (Cel) 260
Current Rating 2A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number TMMDB3
Pin Count 2
Max Output Current 2A
Number of Elements 1
Configuration SINGLE
Case Connection ISOLATED
Trigger Device Type DIAC
Voltage - Breakover 30V~34V
Current - Breakover 15μA
Dimensions
Height 1.62mm
Length 3.4mm
Width 1.62mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
