3P1230002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Thumbwheel Switches
Description
Pushwheel 3P Black 10 Thumbwheel Switch 32.15mm 100mA 28V 0.1A @ 30VDC
PDF
/
Buying Options
Total Price: USD $42.25
Unit Price: USD $42.245183
≥1 USD $42.245183
≥200 USD $16.348231
≥500 USD $15.774494
≥1000 USD $15.490907
Inventory: 3046
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Sections 1
End Caps Included
Section Width 0.300 7.62mm
Output Code BCD Complement
Depth Behind Flange 32.15mm
Contact Rating @ Voltage 0.1A @ 30VDC
Max Voltage Rating (DC) 28V
Electrical Life 100,000 Cycles
Max Current Rating 100mA
Read Out 0 ~ 9
Contact Resistance 300mOhm
Panel Cutout Dimensions Rectangular - 22.50mm x 11.32mm
Actuator Type Pushwheel
Termination Style Card Edge/Solder Pad
Contact Finish Gold
Color Black
Min Operating Temperature -10°C
Max Operating Temperature 65°C
Number of Positions 10
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Dust Lens
Series 3P
Published 2010
Packaging Bulk
Operating Temperature -10°C~65°C
Physical
Housing Material Polycarbonate (PC)
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 13 Weeks
