341100002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Thumbwheel Switches
Description
Switch Thumb-Pushwheel Thumbwheel Decimal 10 0.1A 120VAC 28VDC PC Board Panel Mount
PDF
/
Buying Options
Total Price: USD $120.1
Unit Price: USD $120.1024
≥1 USD $120.1024
≥10 USD $115.6496
Inventory: 80
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Sections 4
End Caps Included
Section Width 0.315 8.00mm
Output Code Decimal
Depth Behind Flange 37.85mm
Contact Rating @ Voltage 0.1A @ 120VAC/28VDC
Max Voltage Rating (DC) 28V
Electrical Life 100,000 Cycles
Max Current Rating 100mA
Max Voltage Rating (AC) 120V
Read Out 0 ~ 9
Contact Resistance 100mOhm
Panel Cutout Dimensions Rectangular - 40.28mm x 31.00mm
Actuator Type Thumbwheel
Termination Style Card Edge/Solder Pad
Color Black
Number of Positions 10
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Dust Lens
Series 3
Published 2010
Packaging Bulk
Operating Temperature -40°C~65°C
Physical
Housing Material Acrylonitrile Butadiene Styrene (ABS)
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 13 Weeks
