DPS9137AK2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Thumbwheel Switches
Description
Pushwheel DPS9 Black 10 Thumbwheel Switch 33mm 1A 0.1A @ 40VAC/DC -20C~80C
PDF
/
Buying Options
Total Price: USD $14.86
Unit Price: USD $14.856776
≥1 USD $14.856776
Inventory: 8661
Minimum: 1
-
+
Technical Details
Technical
HTS Code 8536.50.70.00
Contact Finish Gold
Termination Style Card Edge/Solder Pad
Body Length or Diameter 29mm
Actuator Type Pushwheel
Read Out 0 ~ 9
Contact Current(DC)-Max 1A
Contact Current(AC)-Max 1A
Contact Rating @ Voltage 0.1A @ 40VAC/DC
Number of Switch Sections 1
Depth Behind Flange 39.10mm
Output Code BCD Complement
Section Width 0.315 8.00mm
End Caps Sold Separately
Number of Sections 1
Color Black
Number of Positions 10
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DPS9
Packaging Tray
Operating Temperature -20°C~80°C
Dimensions
Body Height 33mm
Display Characters - Height 0.268 6.80mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Housing Material Polyphenylene Oxide (PPO)
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Material Copper Tin Alloy
Supply Chain
Factory Lead Time 8 Weeks
