MP930-560-1% image
Favorite
MP930-560-1% image
Favorite
RoHS
RoHS RoHS compliant
Package TO-220-2 Full Pack
Category Resistors / Through Hole Resistors
Description Kool-Pak?MP900 FIXED RESISTOR TO-220-2Full Pack Through Hole Resistor ±1% -20/ +80ppm/C 560Ohm 30W
PDF
/
Buying Options
Total Price: USD $5.27
Unit Price: USD $5.2712
≥1 USD $5.2712
≥10 USD $4.5188
≥100 USD $4.357056
≥500 USD $4.052928
≥1000 USD $3.363888
≥3000 USD $3.039696
Inventory: 196
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.650 16.52mm

Technical

Lead Spacing 5.08mm
Resistor Type FIXED RESISTOR
Construction Rectangular
Technology METAL FILM
Subcategory Fixed Resistors
Power (Watts) 30W
Composition Thick Film
Terminal Finish MATTE TIN OVER NICKEL
Resistance 560Ohm
Temperature Coefficient -20/ +80ppm/°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Moisture Resistant, Non-Inductive
JESD-609 Code e3
Tolerance ±1%
Size / Dimension 0.410Lx0.125W 10.41mmx3.18mm
Series Kool-Pak?MP900
Published 2004
Packaging Tube
Operating Temperature -55°C~150°C

Physical

Mounting Feature THROUGH HOLE MOUNT
Terminal Shape FLAT
Surface Mount NO
Package / Case TO-220-2 Full Pack

Supply Chain

Factory Lead Time 9 Weeks
