A10233-30
RoHS
RoHS compliant
RoHS compliantPackage 502
Category Fans, Thermal Management / Thermal - Pads, Sheets
Description
THERM PAD 228.6MMX228.6MM WHITE
PDF
/
Buying Options
Total Price: USD $102.89
Unit Price: USD $102.8896
≥1 USD $102.8896
≥10 USD $96.4568
≥100 USD $90.026464
≥500 USD $86.811296
≥1000 USD $83.596128
Inventory: 62
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Package / Case 502
Material Silicone Elastomer
Shape Square
Technical
Published 2010
Series Tputty? 502
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Sheet
Max Operating Temperature 200°C
Min Operating Temperature -45°C
Color White
Adhesive Tacky - Both Sides
Backing, Carrier Fiberglass
Outline 228.60mm x 228.60mm
Thermal Conductivity 3.0W/m-K
Natural Thermal Resistance 0.49 °C/W
Thermal Resistivity 0.49°C/W
Dimensions
Length 229mm
Width 229mm
Thickness 0.0400 1.016mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 HB
