CA-TX1-050-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / Thermal - Heat Sinks
Description
CERAMIC HEATSINK WITH 1 CLIP
PDF
/
Buying Options
Total Price: USD $7.1
Unit Price: USD $7.102098
≥1 USD $7.102098
≥10 USD $6.700092
≥100 USD $6.320837
≥500 USD $5.963063
≥1000 USD $5.625528
Inventory: 1156
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 1.120 28.45mm
Length 1.970 50.04mm
Technical
Power Dissipation @ Temperature Rise 7.0W @ 50°C
Thermal Resistance @ Natural 5.80°C/W
Thermal Resistance @ Forced Air Flow 3.00°C/W @ 400 LFM
Height Off Base (Height of Fin) 1.650 41.91mm
Attachment Method Clip and PC Pin
Type Board Level, Vertical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series CA
Physical
Material Finish Nickel
Package Cooled TO-247, TO-264
Shape Rectangular, Fins
Material Ceramic
