ATS-PCB1040
RoHS
/
Package TO-220
Category Fans, Thermal Management / Thermal - Heat Sinks
Description
HEATSINK TO-220
PDF
/
Inventory: 2305
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 1.290 32.77mm
Length 1.644 41.76mm
Technical
Thermal Resistance @ Natural 13.40°C/W
Thermal Resistance @ Forced Air Flow 3.90°C/W @ 200 LFM
Height Off Base (Height of Fin) 0.750 19.05mm
Attachment Method Bolt On
Type Board Level
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2014
Physical
Material Finish Black Anodized
Package Cooled TO-220
Shape Rectangular, Fins
Material Aluminum
Package / Case TO-220
Mount Bolt
Supply Chain
Factory Lead Time 6 Weeks
