53-271234
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / Thermal - Flex Heaters
Description
FLEXIBLE HEATER PET 12" WIRES 12
PDF
/
Buying Options
Total Price: USD $82.5
Unit Price: USD $82.5
≥1 USD $82.5
≥10 USD $78.3728
≥100 USD $74.2544
Inventory: 166
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 12.000 304.80mm
Length 24.000 609.60mm
Technical
Power (Watts) @ 12V 288W
Watt Density @ 12V 1 W/in2
Temperature - Peak 250°F 121°C
Attachment Method Pressure Sensitive Adhesive (PSA)
Wire Gauge 18 AWG
Lead Length 12.000 304.80mm
Approval Agency UL
Color Off-White
Resistance 0.5Ohms
Type Foil
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Leads Potted, User Selectable Voltage
Series 53
Physical
Shape Rectangular
Material - Insulation Polyvinyl Chloride (PVC)
Material Polyester
