5005
RoHS
RoHS compliant
RoHS compliantPackage /
Category Test and Measurement / Test Points
Description
KEYSTONE - 5005 - PCB Test Point, Compact, Red, Through Hole Mount, 1.6 mm, Phosphor Bronze, Silver Plated Contacts
PDF
/
Buying Options
Total Price: USD $5.24
Unit Price: USD $5.236
≥1 USD $5.236
Inventory: 58
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Tin
Mount PCB, Through Hole
Mounting Type 0.063 (1.60mm) Hole Diameter
Material Bronze, Nylon, Silver
Material - Insulation Nylon 46, UL 94V-0
Material - Body Phosphor Bronze
Technical
Packaging Bulk
Series THM
Size / Dimension 0.125Diax0.220L 3.18mmx5.59mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type PC Test Point, Compact
Color Red
Orientation Straight
Number of Contacts 1
Plating Silver
Hole Diameter 1.6 mm
Outside Diameter 3.18 mm
Dimensions
Height 5.74mm
Diameter - Inside 1.78 mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
