RoHS
RoHS RoHS compliant
Package /
Category Test and Measurement / Test Points
Description KEYSTONE - 5003 - PCB Test Point, Miniature, Orange, Through Hole Mount, 1 mm, Phosphor Bronze
PDF
/
Buying Options
Total Price: USD $5.24
Unit Price: USD $5.236
≥1 USD $5.236
Inventory: 78
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Diameter - Inside 1.27 mm
Width 6.35mm
Length 9.5mm
Height 6.35mm
Diameter 5.3mm

Technical

Outside Diameter 2.54 mm
Forward Voltage 1.08V
Forward Current 3A
Plating Silver
Color Orange
Type PC Test Point, Miniature
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.100Diax0.180L 2.54mmx4.57mm
Series THM
Packaging Bulk

Physical

Material - Body Phosphor Bronze
Material - Insulation Nylon 46, UL 94V-0
Weight 4.535924g
Material Bronze, Nylon, Silver
Number of Pins 1
Mounting Type 0.040 (1.02mm) Hole Diameter
Mount Through Hole
Contact Plating Tin
Contact Material Bronze

Supply Chain

Factory Lead Time 6 Weeks
