55824-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Wire Splice Connectors
Description
CONN SPLICE BUTT 18-22 AWG RED
PDF
/
Buying Options
Total Price: USD $1.94
Unit Price: USD $1.936
≥1 USD $1.936
≥10 USD $1.72744
≥100 USD $1.718816
≥500 USD $1.701216
≥1000 USD $1.560856
≥3000 USD $1.552109
Inventory: 1167
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 40.79mm
Technical
Government Qualified No
Number of Wire Entries 2
Terminal Type Butt Splice, Inline, Individual Openings
Insulation Fully Insulated Heat Shrink
Insulation Diameter 4.318 mm
Terminal and Terminal Block Type WIRE TERMINAL
Sealable Yes
Wire/Cable Gauge 18 AWG
Body Plating Tin
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Plating Unplated
Wire Gauge 18-22 AWG
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
Color Red
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2003
Packaging Bulk
Physical
Body Material Copper
Insulation Material Polyolefin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 7 Weeks
