10010
RoHS
RoHS compliant
RoHS compliantPackage 300
Category Connectors, Interconnects / Terminals - Wire Splice Connectors
Description
Scotchlok? RoHS Compliant COMMERCIAL UL Butt Splice, Inline, Individual Openings Terminal Connector 105C 1A 1400VAC V 0.68inch
PDF
/
Buying Options
Total Price: USD $136.88
Unit Price: USD $136.884
≥1 USD $136.884
≥10 USD $124.4408
Inventory: 87
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 15μin
Technical
Number of Wire Entries 2
Contact Design PREASSEM CONN
Terminal Type Butt Splice, Inline, Individual Openings
Insulation Non-Insulated
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 1400VAC V
Polarization Key CTR W/GUIDE SLOTS
Body/Shell Style SOCKET
Mating Contact Pitch 0.1 inch
Wire Gauge 300MCM (kcmil)
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender FEMALE
Operating Temperature (Max) 105°C
Body Length or Diameter 0.68 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 10
Option WITH CABLE ASSEMBLY
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD (15) OVER NICKEL (30)
Subcategory Headers and Edge Type Connectors
Additional Feature 3M
Number of Rows 2
Color White
Connector Type BOARD CONNECTOR
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Copper Wire Only
JESD-609 Code e4
Series Scotchlok?
Published 2014
Packaging Bulk
Physical
Insulation Material GLASS FILLED POLYESTER
Package / Case 300
Mounting Type CABLE
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 3 Weeks
