1633-3 image
Favorite
1633-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Turret Connectors
Description Circuit Board Hardware - PCB DBL END TURRET .115 "L" BRASS
PDF
/
Buying Options
Total Price: USD $0.24
Unit Price: USD $0.2376
≥1 USD $0.2376
≥10 USD $0.19536
≥100 USD $0.169752
≥500 USD $0.158998
≥1000 USD $0.141064
≥3000 USD $0.114013
Inventory: 1162
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Diameter - Turret Head 0.045 (1.14mm)
Length - Above Board 0.076 1.93mm
Length - Below Flange 0.255 6.48mm
Board Thickness 0.093 2.36mm
Length - Overall 0.331 8.41mm
Length 8.4074mm
Diameter 1.57mm

Technical

Number of Turrets Single
Flange Diameter 0.078 (1.98mm)
Hole Diameter 1.6256 mm
Terminal Type Double End, Pin
Insulation Non-Insulated
Terminal and Terminal Block Type PCB TERMINAL
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Staking Flare
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2004

Physical

Mounting Hole Diameter 0.064 (1.63mm)
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass

Supply Chain

Factory Lead Time 6 Weeks
