1613-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Turret Connectors
Description
Circuit Board Hardware - PCB .113 TURRET
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.285818
≥1 USD $0.285818
≥10 USD $0.269632
≥100 USD $0.254375
≥500 USD $0.23998
≥1000 USD $0.226392
Inventory: 994
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Turret Head 0.050 (1.27mm)
Length - Above Board 0.186 4.72mm
Length - Below Flange 0.195 4.95mm
Board Thickness 0.093 2.36mm
Length - Overall 0.381 9.68mm
Length 9.6774mm
Diameter 1.57mm
Technical
Staking Side OD 0.062 (1.57mm)
Number of Turrets Single, Double
Flange Diameter 0.093 (2.36mm)
Hole Diameter 1.7018 mm
Terminal Type Double End
Insulation Non-Insulated
Terminal and Terminal Block Type PCB TERMINAL
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Staking Flare
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2004
Physical
Mounting Hole Diameter 0.067 (1.70mm)
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
