1593-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Turret Connectors
Description
Circuit Board Hardware - PCB .054 X .032 TUR TERM
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.221672
≥1 USD $0.221672
≥10 USD $0.209122
≥100 USD $0.197284
≥500 USD $0.186118
≥1000 USD $0.175587
Inventory: 8320
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Mounting Hole Diameter 0.067 (1.70mm)
Technical
Published 2008
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Staking Flare
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Terminal and Terminal Block Type PCB TERMINAL
Insulation Non-Insulated
Terminal Type Single End
Hole Diameter 1.7018 mm
Flange Diameter 0.094 (2.39mm)
Number of Turrets Double
Staking Side OD 0.062 (1.57mm)
Dimensions
Diameter 1.57mm
Length 5.334mm
Length - Overall 0.210 5.33mm
Board Thickness 0.032 0.81mm
Length - Below Flange 0.054 1.37mm
Length - Above Board 0.156 3.96mm
Diameter - Turret Head 0.062 (1.57mm)
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
