1582-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Turret Connectors
Description
Circuit Board Hardware - PCB TERMINAL
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.509472
≥1 USD $0.509472
≥10 USD $0.480636
≥100 USD $0.453431
≥500 USD $0.427763
≥1000 USD $0.403543
Inventory: 1189
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Turret Head 0.109 (2.77mm)
Length - Above Board 0.328 8.33mm
Length - Below Flange 0.167 4.24mm
Board Thickness 0.125 3.18mm
Length - Overall 0.495 12.57mm
Length 12.573mm
Diameter 2.01mm
Technical
Staking Side OD 0.078 (1.98mm)
Number of Turrets Double
Flange Diameter 0.156 (3.96mm)
Hole Diameter 2.0828 mm
Terminal Type Single End, Hollow
Insulation Non-Insulated
Terminal and Terminal Block Type PCB TERMINAL
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Staking Flare
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2004
Physical
Mounting Hole Diameter 0.082 (2.08mm)
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
