1582-2
RoHS
RoHS compliant
RoHS compliantPackage 062
Category Connectors, Interconnects / Terminals - Turret Connectors
Description
Circuit Board Hardware - PCB PCB TURRET TERM
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.59483
≥1 USD $0.59483
≥10 USD $0.561158
≥100 USD $0.529396
≥500 USD $0.499433
≥1000 USD $0.471163
Inventory: 3814
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Package / Case 062
Mounting Hole Diameter 0.082 (2.08mm)
Technical
Published 2004
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Staking Flare
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Terminal and Terminal Block Type PCB TERMINAL
Insulation Non-Insulated
Terminal Type Single End, Hollow
Hole Diameter 2.0828 mm
Flange Diameter 0.156 (3.96mm)
Number of Turrets Double
Staking Side OD 0.078 (1.98mm)
Dimensions
Diameter 2.01mm
Length 11.049mm
Length - Overall 0.435 11.05mm
Diameter - Inside 1.4 mm
Board Thickness 0.062 1.57mm
Length - Below Flange 0.107 2.72mm
Length - Above Board 0.328 8.33mm
Diameter - Turret Head 0.109 (2.77mm)
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
