1532-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Turret Connectors
Description
TERM TURRET SINGLE L=5.94MM TIN
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.381702
≥1 USD $0.381702
≥10 USD $0.360091
≥100 USD $0.339717
≥500 USD $0.320484
≥1000 USD $0.302345
Inventory: 9079
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Turret Head 0.145 (3.68mm)
Length - Above Board 0.234 5.94mm
Length - Below Flange 0.165 4.19mm
Board Thickness 0.125 3.18mm
Length - Overall 0.399 10.13mm
Length 10.1346mm
Diameter 2.84mm
Technical
Staking Side OD 0.112 (2.84mm)
Number of Turrets Single
Flange Diameter 0.187 (4.75mm)
Hole Diameter 2.9464 mm
Terminal Type Single End
Insulation Non-Insulated
Terminal and Terminal Block Type PCB TERMINAL
Row Spacing 50.8 mm
Contact Finish Tin
Pitch 9.525mm
HTS Code 8536.90.40.00
Number of Rows 2
Number of Positions 52
ECCN Code EAR99
Termination Staking Flare
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2008
Physical
Mounting Hole Diameter 0.116 (2.95mm)
Material Glass
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
