1526-2
RoHS
RoHS compliant
RoHS compliantPackage 062
Category Connectors, Interconnects / Terminals - Turret Connectors
Description
TERM TURRET HOLLOW L=3.96MM TIN
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.356928
≥100 USD $0.349272
≥500 USD $0.327149
≥1000 USD $0.290224
≥3000 USD $0.189904
Inventory: 1358
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length - Above Board 0.156 3.96mm
Length - Below Flange 0.084 2.13mm
Board Thickness 0.062 1.57mm
Length - Overall 0.240 6.10mm
Length 6.09mm
Diameter 2.3876mm
Technical
Staking Side OD 0.062 (1.57mm)
Number of Turrets Single
Flange Diameter 0.094 (2.39mm)
Hole Diameter 1.6256 mm
Terminal Type Single End, Fork, Hollow
Insulation Non-Insulated
Terminal and Terminal Block Type PCB TERMINAL
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Staking Flare
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2004
Physical
Mounting Hole Diameter 0.064 (1.63mm)
Package / Case 062
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
