1519-1 image
Favorite
1519-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Turret Connectors
Description Circuit Board Hardware - PCB .078 tubular turret
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.400107
≥1 USD $0.400107
≥10 USD $0.377462
≥100 USD $0.356093
≥500 USD $0.335931
≥1000 USD $0.316914
Inventory: 1140
Minimum: 1
-
+

Technical Details

Technical

Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Staking Flare
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Terminal and Terminal Block Type PCB TERMINAL
Insulation Non-Insulated
Terminal Type Single End, Hollow
Hole Diameter 2.8702 mm
Flange Diameter 0.187 (4.75mm)
Number of Turrets Single
Staking Side OD 0.110 (2.79mm)
Part Status Active
Published 2004

Dimensions

Diameter 2.84mm
Length 6.731mm
Length - Overall 0.265 6.73mm
Board Thickness 0.032 0.81mm
Length - Below Flange 0.078 1.98mm
Length - Above Board 0.187 4.75mm
Diameter - Turret Head 0.140 (3.56mm)

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free

Physical

Mounting Hole Diameter 0.113 (2.87mm)
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass

Supply Chain

Factory Lead Time 6 Weeks
