8-52948-1
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
Terminal Spade Connector
PDF
/
Inventory: 3131
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Free Hanging
Insulation Material Vinyl
Body Material Bronze
Technical
Packaging Bulk
Termination Crimp
ECCN Code EAR99
Color Red
HTS Code 8536.90.40.00
Voltage - Rated AC 600V
ELV Compliant
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 22 AWG
Terminal and Terminal Block Type FORK TERMINAL
Insulation Diameter 3.556 mm
Insulation Insulated
Wire/Cable Diameter 3.56 mm
Wire Cross Section 1.65 mm2
Insulated Wire Support Yes
Heavy Duty No
Terminal Gender FEMALE
Stud Diameter 3.18 mm
Stud Size M3
Dimensions
Length 20.5994mm
Tongue Thickness 840μm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
