PV14-6F-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
Fork Terminal 14-16AWG 21.3mm 7.1mm Tin
PDF
/
Buying Options
Total Price: USD $1.04
Unit Price: USD $1.037137
≥1 USD $1.037137
≥10 USD $0.978431
≥100 USD $0.923042
≥500 USD $0.870806
≥1000 USD $0.821511
Inventory: 6693
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Vinyl
Technical
Packaging Bulk
Published 2011
Series Pan-Term?
Feature Brazed Seam, Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp
Color Blue
Contact Finish Tin
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Insulation Diameter 0.170 (4.32mm)
Insulation Insulated
Terminal Type Standard
Stud/Tab Size 6 Stud
Tongue Inside Opening 0.150 (3.81mm)
Dimensions
Length 21.336mm
Length - Overall 0.840 21.34mm
Width - Outer Edges 0.280 7.11mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Alternative Model
