0191210056
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 10-12AWG #10 YEL
PDF
/
Inventory: 7439
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Copper
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Bulk
Series InsulKrimp
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Yellow
Contact Finish Electro-Tin
Wire Gauge 10-12 AWG
Insulation Diameter 0.245 (6.22mm)
Insulation Insulated
Terminal Type Flanged
Stud/Tab Size 10 Stud
Tongue Inside Opening 0.209 (5.31mm)
Dimensions
Length - Termination 0.550 13.97mm
Length - Overall 1.010 25.65mm
Width - Outer Edges 0.385 9.78mm
Length - Ring Center to Termination 0.270 6.86mm
Compliance
RoHS Status ROHS3 Compliant
